Tannoy Reveal 402(ea)
Don’t be fooled by Reveal 402’s compact size. Decades of experience in loudspeaker design and tweaking is the foundation for creating Reveal 402. The result is a massive soundscape generated by the super-efficient 4” woofer and ultra-precise ¾” tweeter.
Don’t be fooled by Reveal 402’s compact size. Decades of experience in loudspeaker design and tweaking is the foundation for creating Reveal 402. The result is a massive soundscape generated by the super-efficient 4” woofer and ultra-precise ¾” tweeter.
General Specifications
- 4” (100 mm)
- Bi-amp Output Power, RMS
- Power Output50 WattsLF/Mid Range25 WattsHF25 WattsTHD< 0.9 %
- Input Types and Impedances
- BalancedXLR, 20 kOhmUnbalanced¼" Jack, 10 kOhmAUX LinkMini Jack, 10 kOhmAUX Link OutputMini Jack
- EQ Options
- HF EQ Settings-1.5 dB HF Cut / Neutral / +1.5 dB HF BoostCrossover Frequency2.8 kHzLow Frequency AlignmentOptimized Front Port
- Cabinet Dimensions
- HxWxD, inches9.5 x 5.8 x 8.4HxWxD, mm240 x 147 x 212
