CL5G3PK1

Specifications:

• Configuration: 2-Way
• System Type: Active Studio Monitor
• Low-Frequency Transducer: 5″ Glass Aramid Woofer
• High-Frequency Transducer: 1″ Textile Soft Dome Tweeter
• Frequency Response (+/- 3dB): 56Hz – 30kHz
• Frequency Range (-10dB): 46Hz – 34.5kHz
• Crossover Frequency: 2.6kHz
• Average Beamwidth (Horizontal): 133 Degrees (900 Hz — 9 kHz)
• Average Beamwidth (Vertical): 90 Degrees (900 Hz — 9 kHz)
• Max Peak SPL (With Limiter): 101 dB
• Max Average SPL (With Limiter): 98 dB
• Max Calculated SPL: 99 dB
• Amplifiers: Class A-B
• High-Frequency Power Output (Watts): 20 Watts
• Low-Frequency Power Output (Watts): 30 Watts
• Amplifier Distortion (THD+N): < 0.1% THD+N (20 Hz — 20 kHz at -3 dB Max Power)
• Input Impedance (Ohms): 10 KΩ Balanced / 7 KΩ Unbalanced
• Input Sensitivity: 0 dBu Balanced / -15 dBV Unbalanced
• SNR (Signal to Noise Ratio): > 94 dB
• Controls:
  • System Volume: -30 dB – +6 dB
  • LF Level Adjust: (-1 dB, FLAT, +1 dB, +2 dB) Below 200 Hz
  • HF Level Adjust: (-2 dB, -1 dB, FLAT, +1 dB) Above 2.6 kHz
• Indicators: Power
• Input Connectors: RCA, Balanced 1/4″ TRS, Balanced XLR
• Output Connectors: N/A
• AC Fuse (Slow Blow / Time Lag):
  • 120 VAC (T1AL, 250 V)
  • 240 VAC (T500mAL, 250 V)
• Idle (Mute) AC Power Consumption: 14 Watts (NA SKU)
• Maximum AC Power Consumption: 79 Watts (NA SKU)
• Enclosure Construction: 15 mm MDF / High Impact Polystyrene
• Finish: Black Vinyl Wrap
• Grille: N/A
• Hardware: Foam Isolation Pads
• Product Dimensions (H x W x D): 9.68″ (246mm) x 7.40″ (188mm) x 11.20″ (284mm)
• Product Weight: 12.95 lb (5.87 kg)
