Wharfedale Tourus AX15MBT
Tourus loudspeakers use the largest HF voice coils in their class. All models use a 1.75″ coil which is unique at this price point.
| Model Name | TOURUS-AX15-MBT |
| System Type | Active 15” 2-way Bi-Amplified |
| Frequency Response (+/-3 dB) | 50-20 KHz |
| Sensitivity @ 1 w / 1 meter | 97 dB |
| Maximum SPL (peak @ 1 meter) | 130 dB |
| Low Frequency Transducer | |
| Size (mm / inches) | 381 mm / 15” |
| Coil Size (mm / inches) | 50.8 mm / 2.0” |
| Impedance | 4 Ω |
| High Frequency Transducer | |
| Type | Compression Driver |
| Coil Size (mm / inches) | 44.5 mm / 1.75” |
| Exit Size (mm / inches) | 25 mm / 1” |
| Diaphragm Material | Titanium |
| Impedance | 8 Ω |
| High Frequency Coverage (H x V) | 90° x 60° |
| Amplifiers | HF Amp Class AB : LF Amp Class D |
| Low-Frequency Power Amplifier | 350 w Continuous / 700 w Peak |
| High- Frequency Power Amplifier | 100 w Continuous / 200 w Peak |
| Electronic Crossover | |
| Crossover Frequency | HI PASS 2.4 KHz LOW PASS 2.4 KHz |
| Controls | |
| Equalization | +/-12 dB Gain for bass and treble |
| Amplifier Protection | |
| Power On Protection | Power switch on / off mute |
| Thermal Protection | Amplifier shutdown, auto reset |
| Driver, DC and Short Protection | Yes |
| Limiter Indicator | Red LED |
| Power Indicator | Green LED |
| Input type | Balanced / BT / USB |
| Input Connectors | 2 x TRS JACK, 2 x RCA AND 2 x FEMALE XLR |
