M SQ DANT32 AX
The Allen Heath M SQ DANT32 AX is a high-performance Dante audio networking module specifically designed for the SQ series digital mixers. This advanced Version 2 module offers a 32x32 channel audio interface, enabling seamless integration with Dante-enabled devices.
| General | |
| AES67 Support | Yes |
| Audinate Chipset | Brooklyn II |
| Audio Channels Input | 32 |
| Audio Channels Output | 32 |
| Audio Network Card Type | Expansion Module |
| Bit Depth Support | 24-bit |
| Compatibility | Allen & Heath SQ Series Consoles |
| Compatibility Functions | Dante-enabled devices interoperability |
| Compliance Certifications | CE, FCC |
| Connection Type | Ethernet |
| Connector Type | RJ45 |
| Control Software | Dante Controller |
| Dante Controller Compatibility | Yes |
| Dante Virtual Soundcard Compatibility | Yes |
| Device Discovery | Automatic on network |
| Dimensions (WxHxD) | 170 x 105 x 33 mm |
| Firmware Update Method | Via Dante Controller |
| Firmware Upgradable | Yes |
| Hot-swappable | Yes |
| Intended For | SQ Series Mixing Consoles |
| Latency | <1 ms (network dependent) |
| Manufacturer | Allen & Heath |
| Manufacturing Origin | United Kingdom |
| Model | M SQ DANT32 AX |
| Mounting Method | Internal Slot (Module Bay) |
| Multicast/Unicast Capability | Yes, both supported |
| Network Audio Protocol | Dante |
| Network Cable Type | CAT5e or higher |
| Network Topologies Supported | Star, Daisy Chain (Limited) |
| Number of Network Ports | 2 |
| Operating temperature range | 0°C to 40°C (32°F to 104°F) |
| Plug-and-Play Operation | Yes |
| Port Type | Gigabit Ethernet |
| Power Consumption | max 6.5W |
| Power Source | Module slot via SQ console |
| Primary/Secondary Port Usage | Redundant networking |
| Product Color | Black |
| Product Type | Dante Audio Networking Module |
| Redundancy Support | Yes |
| Sample Rates Supported | 44.1 kHz, 48 kHz, 96 kHz |
| Storage Temperature Range | -20°C to 60°C (-4°F to 140°F) |
| Supported Console Version | SQ Version 2 |
| Supported Network Modes | Switched, Redundant |
| Supported Operating Systems for Control | Windows, MacOS |
| Supporting QoS | Yes |
| Switchable Sample Rate | Yes |
| Total Audio Channels | 64 |
| Transport Protocol | Dante Audio-over-Ethernet |
| UPC/EAN | 6938122251412 |
| Weight | 0.46 kg |
