Allen & Heath CQ 20B RK19

Core Performance Features

• Perfect 19" Enclosure Formatting: Modifies the physical width of the CQ-20B stage box to align exactly with standard global 19-inch equipment racks. This ensures a clean, seamless look when racked alongside wireless mic receivers, drawer units, power conditioners, or companion power amplifiers.

• Heavy-Gauge Steel Build: Stamped from industrial-strength, thick-gauge rolled steel alloy. These brackets are designed to easily support the dead weight of the mixer without bowing or flexing, even when subjected to intense vertical shocks during transit on bumpy roads.

• Preserved Rear Ventilation Clearance: The geometry of the ears extends the front lip of the mixer out slightly. This leaves ample internal ventilation space around the side intake vents and rear power switch, ensuring the mixer's internal DSP core runs cool under heavy long-duration processing loads.

• Impact-Resistant Powder Coating: Finished in a matching scuff-resistant matte black industrial powder coat. This matching texture mirrors the original finish of the mixer's side panels while defending the mounting hardware from scratches, metal chips, and rust.

• Fast, Non-Invasive Assembly: Engineered for seamless physical integration using factory attachment holes. The kit mounts securely to the sides of the mixer chassis using existing case thread layouts, meaning no drilling or custom modification of your primary mixer housing is required.

Technical Layout & Specifications

• Type: 19-inch Equipment Rackmount Ear Kit.

• Compatibility: Exclusively tailored for the Allen & Heath CQ-20B digital mixer (not compatible with the smaller CQ-12T or screen-based CQ-18T variations).

• Rack Space Requirement: Occupies a vertical height of 4U inside a standard equipment rail system.

• Material Composition: Heavy-duty powder-coated steel alloy plates.

• Mounting Layout: Pre-drilled with standard oblong rack holes to fit standard rack screws and clip-on cage nuts.
