AKG C414 XLS ST
The C414 XLS reference multi-pattern condenser microphone offers a choice of nine polar patterns for the perfect sonic capture for every application. The C414 XLS maintains the sonic character of the legendary C414 B-ULS, the most popular AKG C414 version since 1971. Engineered for highest linearity and neutral sound, it has been the most versatile large-diaphragm microphone for decades.
General Specifications
- Audio frequency bandwidth
- 20 - 20000 Hz
- Equivalent noise level
- 6 dB-A
- Sensitivity
- 23 mV/Pa
- Signal to Noise
- 88 dB-A
- Preattenuation Pad
- -6; -12; -18 dB
- Bass cut filter
- 160; 80; 40 Hz
- Electrical impedance
- 200 Ohms
- Recommended load impedance
- 2000 Ohms
- Polar Patterns
- Cardioid, Figure of eight, Hypercardioid, Omnidirectional, and Wide Cardioid
Audio Output
- Type
- Balanced XLR
- Gender
- Male
- Contacts
- 3-pin
Powering Interface
- Voltage
- 44 to 52 V
- Current
- 4.5 mA
Application
- Pro Studio
